ASTM D3364 PLC Control Melt Flow Rate Meter MFR & MVR For Meltblown Fabric

Product name : PLC Melt Flow Rate Meter MFR & MVR

Die length : 8.000±0.025mm

Cylinder length : 152±0.1 mm

Cylinder diameter : Ф9.550±0.025mm

Length of piston head : 6.350±0.100mm

Diameter of piston head : 9.475±0.015 mm

Temperature range : 50℃-450℃

Resolution : 0.1℃

Power : 220V±10% 60Hz

Temperature constant accuracy : ±0.2℃

Brand Name : ZL

Model Number : ZL-3014C

Certification : CE,ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 60 Sets

Delivery Time : 5-8 work days

Packaging Details : PLC Melt Flow Rate Meter is packaged within wooden case.

Contact Now

ASTM D3364 PLC Control Melt Flow Rate Meter MFR & MVR For Meltblown Fabric

Product Overview

ASTM D3364 PLC Control Melt Flow Rate Meter MFR & MVR For PC, FI, Plastics, etc.

Download Product Brief

Applications

The ZL-3014C Melt Flow Indexer meets the requirements of GB/T3682-2000, ASTM D3364 (and ASTM D1238-98). Designed with reference to similar standards including JB/T5456 and ISO 1133, this instrument is used to determine the melt mass-flow rate (MFR) and melt volume-flow rate (MVR) of thermoplastic materials.

For MFR determination, the instrument employs automatic sampling with cut samples weighed by balance. For MVR determination, it measures the time required for the piston to move a specified distance using displacement transducers and an automatic timer system, then calculates MVR according to the formula.

Both methods display final results on the machine's LCD screen and provide printed output and computer export capabilities. The instrument offers high measurement accuracy, simple operation, and stable performance.

Suitable for testing engineering plastics with higher melt temperatures (PC, FI plastics, nylon) as well as plastics with lower melt temperatures (PE, PP, POM, PS, ABS resin, poly carbonic acid ester, etc.).

Widely used in plastic fabrication, plastic goods manufacturing, petrochemical industries, colleges and universities, research institutes, and commodity inspection departments.

Technical Specifications

Extrusion Section

Component	Specification
Die length	8.000±0.025mm
Die diameter	Ф2.095±0.005mm
Cylinder length	152±0.1 mm
Cylinder diameter	Ф9.550±0.025mm
Length of piston head	6.350±0.100mm
Diameter of piston head	9.475±0.015 mm

Temperature range: 50℃-450℃
Temperature constant accuracy: ±0.2℃
Resolution: 0.1℃
Power: 220V±10% 60Hz

Standard Test Load (8 grades)

1st grade: 0.325kg = (piston stem + weight tray + heat insulation sheath + weight #1) = 3.187N
2nd grade: 1.200kg = (0.325 + weight #2 0.875) = 11.77N
3rd grade: 2.160kg = (0.325 + weight #3 1.835) = 21.18N
4th grade: 3.800kg = (0.325 + weight #4 3.475) = 37.26N
5th grade: 5.000kg = (0.325 + weight #5 4.675) = 49.03N
6th grade: 10.000kg = (0.325 + weight #5 4.675 + weight #6 5.000) = 98.07N
7th grade: 12.500kg = (0.325 + weight #5 4.675 + weight #6 5.000 + weight #7 2.500) = 122.58N
8th grade: 21.600kg = (0.325 + weight #2 0.875 + weight #3 1.835 + weight #4 3.475 + weight #5 4.675 + weight #6 5.000 + weight #7 2.500 + weight #8 2.915) = 211.82N

Test load relative error shall not exceed ±0.5%.
