5030C Dual Search Unit X - Ray Security Scanner , 1-64 Times Stepless Amplification

Brand Name : ZL

Model Number : ZL-4005

Certification : CE,ISO

Place of Origin : CHINA

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C, T/T, Western Union

Supply Ability : 60 sets / month

Delivery Time : 5-8 work days

Packaging Details : 5030C Dual Search Unit X-Ray Security Scanner is packaged within wooden case.

Product name : 5030C Dual Search Unit X-Ray Security Scanner

Maximum load capacity : 150Kg

Penetration : 10mm steel plate

Conveyor speed : 0.22 m seconds

Channel size : 500 (W) x 300 (H) mm

Power : <0.5kw/h

Working voltage : 110~240VAC (-10%~+20%) 50/60±3Hz

Penetration resolution : Φ0.127mm, wire

Contact Now

5030C Dual Search Unit X-Ray Security Scanner
Product Overview
5030C Dual Search Unit X-Ray Security Scanner with 1-64 times stepless amplification capability for comprehensive security screening applications.
Applications & Usage Scope
Rapid and effective detection of various dangerous goods across multiple security-sensitive environments including:
  • Transportation hubs: Bus stations, railway stations, high-speed rail stations, airports
  • Government facilities: Customs, government agencies, embassies, courts
  • Public venues: Convention centers, tourist attractions, sports facilities, hotels, schools
  • Commercial operations: Post offices, express delivery companies, manufacturing facilities
System Functions
  • Power-on self-test function
  • Multi-level user management
  • Curve diagnosis and image management
  • Equipment information query
  • OSD operation function
  • Multi-format image export
  • Image mirroring and 1-64 times stepless amplification
  • Operator training capabilities
  • Precise package image positioning
  • Remote operation software
  • One-touch shutdown
Scanner Functions
Advanced image processing capabilities including:
  • Color and black/white imaging
  • High wear and low wear modes
  • Local enhancement and super increase
  • Organic rejection and inorganic removal
  • Reverse color and highlighting
  • Darkening and gray sweeping
  • Magnification and pseudo-color
  • Organic enhancement
  • Suspicious object alarm mark
  • Edge enhancement processing
X-Ray Generator Specifications
  • Tube voltage: 80kV (default), customizable per customer requirements
  • Tube current: 0.2~0.6mA
  • Cooling/working time: Sealed oil cooling / 100% duty cycle
  • Beam direction: Bottom diagonal divergence (60° angle)
Basic Parameters
Parameter Specification
Maximum Load Capacity 150Kg
Penetration 10mm steel plate
Conveyor Speed 0.22 m/second
Penetration Resolution Φ0.127mm wire
Line Resolution Φ0.0787mm wire
Noise ≤55dB
Spatial Resolution Horizontal: Φ1.0mm, Vertical: Φ1.0mm
Radiation Safety Indicators
Single dose: Less than 1 micro sievert (μGy)
Leakage radiation dose rate: Less than 0.3 micro sievert (μGy) at 5cm from device surface
Complies with and exceeds domestic and international health and safety standards
Efficient anti-radiation: Double-layer staggered, wear-resistant, strong lead curtain with ultra-thick 2~5mm lead plate
Film Safety: Safe for SO1600 film
Installation Parameters
Parameter Specification
Channel Size 500 (W) x 300 (H) mm
Conveyor Height 740mm
Product Size 1550mm (L) x 720mm (W) x 1193mm (H)
Wooden Box Packaging Size 1750mm (L) x 850mm (W) x 1400mm (H)
Net Weight 200kg
Gross Weight 250kg
Display Standard 19-inch (16:10/1440×900) display
Keyboard PC keyboard, optional industrial keyboard
Operating Temperature -20°C to +60°C
Operating Humidity 5% to 95% (no condensation)
Storage Temperature -30°C to +70°C
Storage Humidity 5% to 95% (no condensation)
Working Voltage 110~240VAC (-10%~+20%) 50/60±3Hz
Power Consumption <0.5kW/h
Certification Complies with IEC electrical safety standards, meets CE requirements (EMC/LVD/ROHS)
Product Images
5030C Dual Search Unit X - Ray Security Scanner , 1-64 Times Stepless Amplification 5030C Dual Search Unit X - Ray Security Scanner , 1-64 Times Stepless Amplification 5030C Dual Search Unit X - Ray Security Scanner , 1-64 Times Stepless Amplification
