IEC68-2 Dual Controller Constant Temperature And Humidity Chamber

  • 1
  • 2
  • 3

Power : 1Φ 220VAC±10% 50/60Hz & 3Φ 380VAC±10% 50/60Hz

Heating / cooling time : About 4.0℃/min；about 1.0℃/min（5~10℃/mm is the specific condition)

Temperature range : -70℃~+100℃(150℃)

Accuracy/ uniformly : ±0.1℃；±0.1%R.H./ ±1.0℃；±3.0%R.H.

Inside material : Stainless steel SUS 304#

Humidity range : 20%~98%R.H.(10%-98%R.H/5%~98%R.H is the specific condition)

Brand Name : ZL

Model Number : ZL-6004

Certification : CE,ISO

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : L/C,T/T,Western Union

Supply Ability : 60 Sets

Delivery Time : 5-8 work days

Packaging Details : IEC68-2 Dual Controller Constant Temperature and Humidity Testing Chamber is packaged within wooden case.

Product name : IEC68-2 Dual Controller Constant Temperature and Humidity Testing Chamber

Key words : Dual Controller

Contact Now

\n
\n
\n
IEC68-2 Dual Controller Constant Temperature and Humidity Chamber
\n
\n This dual controller constant temperature and humidity testing chamber is constructed from stainless steel 304 and designed for comprehensive material testing under various environmental conditions including heat resistance, cold resistance, dry resistance, and moisture resistance.\n
\n
\n
\n
Equipment Overview
\n
\n The chamber features simple operation and easy program editing capabilities, with clear display of set values and operational time. It provides reliable testing for quality control across multiple industries.\n
\n
\n
\n
Compliance Standards
\n
    \n
  • International Electrotechnical Commission: IEC68-2-03 (Ca), IEC68-2-01 (A), IEC68-2-02 (B)
    • \n
  • industrial Standards: MIL-STD-810F (507.4, 501.4, 502.4), MIL-STD883C, MIL-STD810D
    • \n
  • Japanese Industrial Standard: JIS C60068-2-3, JIS C60068-2-2, JIS C60068-2-1
    • \n
  • USA Semiconductor Industry: JESD22-A101-B, JESD22-A103-C, JESD22-A119
    • \n
  • Chinese National Standard: GB11158, GB10589-89, GB10592-89, GB/T10586-89, GB/T2423 series
    • \n
  • China's National industrial: GJB150.3, GJB150.4, GJB150.9
    • \n
\n
\n
\n
Key Features
\n
    \n
  • High-texture appearance with matte stripe surface treatment and planar non-reactive handles
    • \n
  • Rectangular complex glass viewing window with anti-sweat heater and high-brightness PL light
    • \n
  • Double-insulated airtight container for effective temperature isolation
    • \n
  • External water supply system with automatic water reuse capability
    • \n
  • French "Taikang" compressor circulatory system with environmentally friendly refrigerants (R23, R404, R507)
    • \n
  • Imported LCD display controller showing measured values, settings, and time
    • \n
  • Multi-segment program editing with quick or slope temperature/humidity control
    • \n
  • Built-in mobile pulley system with strong positioning screw for stability
    • \n
\n
\n
\n
Applications
\n
\n Electronic components, plastic products, electrical appliances, instruments, food products, vehicles, metals, chemicals, building materials, aerospace components, and medical equipment.\n
\n
\n
\n
Power Requirements
\n
\n Three-phase 380V \u00b110%, Power frequency: 50Hz \u00b12%, 4KW\n
\n
\n
\n
Technical Specifications
\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n\n
ModelZL-80 (A~G)ZL-150 (A~G)ZL-225 (A~G)ZL-408 (A~G)ZL-608 (A~G)ZL-800 (A~G)ZL-1000 (A~G)
Inside Size WxHxD (cm)40x50x4050x60x5050x75x6060x85x8080x95x80100x100x80100x100x100
Outside Size WxHxD (cm)100x170x87105x175x97115x190x97135x195x115145x185x137145x210x130147x210x140
Temperature Range-70\u2103~+100\u2103(150\u2103) (A:+25\u2103 B:0\u2103 C:-20\u2103 D:-40\u2103 E:-50\u2103 F:-60\u2103 G:-70\u2103)
Humidity Range20%~98%R.H. (10%-98%R.H/5%~98%R.H specific conditions available)
Accuracy/Uniformity\u00b10.1\u2103; \u00b10.1%R.H./ \u00b11.0\u2103; \u00b13.0%R.H.
Accuracy/Volatility\u00b11.0\u2103; \u00b12.0%R.H./ \u00b10.5\u2103; \u00b12.0%R.H.
Heating/Cooling TimeApprox. 4.0\u2103/min; approx. 1.0\u2103/min (5~10\u2103/min specific conditions)
\n
\n
\n
Construction Details
\n
Materials & Components
\n
\nInside Material: Stainless Steel SUS 304#
\nInsulation Material: High-temperature high-density amino acid ethyl ester foam
\nCooling System: Air-cooled/single-stage compressor (-20\u2103), wind/water cooled/two-stage compressor (-40\u2103~-70\u2103)
\nSafety Protection: Compressor overload switch, high/low pressure protection, over-humidity-temperature protection, fuses, warning system
\nStandard Accessories: Recorder (optional), view window, 50mm testing hole, PL lamp, clapboard, dry and wet gauze ball
\nController: TEMI300 digital controller (South Korea)
\nCompressor: France Tecumceh
\nPower: 1\u03a6 220VAC\u00b110% 50/60Hz & 3\u03a6 380VAC\u00b110% 50/60Hz\n
\n
\n
\n
System Configuration
\n
Wind Circulative System
\n
    \n
  • Multi-wing centrifugal rewind fans with aluminum alloy axis for forced convection
    • \n
  • Stainless steel added long axis construction
    • \n
  • Stainless steel multi-blade centrifugal wind wheel
    • \n
\n
Water Supply System
\n
    \n
  • Rear-mounted water tank
    • \n
  • Automatic water supply
    • \n
  • Low water level warning system
    • \n
\n
Cooling System
\n
    \n
  • Compressor: France "Tecumceh" Hermetic Refrigeration Compressor TFHK2522K (two units)
    • \n
  • Refrigerator: Air-cool condenser coil
    • \n
  • Evaporator: Pomfret chip multi-segment design
    • \n
  • Accessories: Imported desiccant cooling, Freon-borne window, US oil-water separator
    • \n
  • Expansion System: Italian expansion valve
    • \n
\n
Temperature & Humidity Control
\n
    \n
  • Controller: South Korea TEMI850 color LCD touch screen (English/Chinese)
    • \n
  • Accuracy: \u00b10.5\u2103 \u00b11% R.H., Resolution: 0.1\u2103 1% R.H.
    • \n
  • 999 program memory capacity with single-stage or multi-segment program control
    • \n
  • RS-232 communication interface for computer connectivity and data recording
    • \n
  • Comprehensive safety inspection and fault display system
    • \n
  • Cumulative operating time display
    • \n
  • Sensor: PT100 precision sensor
    • \n
\n
\n
\n
Service & Support
\n
    \n
  • Complete documentation including equipment drawings, electrical schematics, wiring diagrams, and operating manuals
    • \n
  • Comprehensive operator and maintenance training
    • \n
  • One-year warranty with free maintenance service
    • \n
  • Cost-price accessories available after warranty period
    • \n
\n
\nIEC68-2 Dual Controller Constant Temperature And Humidity Chamber\n
